| Printing Method |
Piezo ink-jet method |
| Media |
Width |
335 to 1,625 mm (13.2 to 64 in.) |
295 to 1,371 mm (11.7 to 54 in.) |
| Thickness |
Max. 1.0 mm (39.3 ml) with liner, for printing
Max. 0.4 mm (15.7 m) with liner and 0.22 mm (8.6 ml) without liner, for cutting |
| Roll outer diameter |
Max. 250 mm (9.84 in.) |
| Roll weight |
Max. 45 kg (99 lb.) |
Max. 35 kg (77 lb.) |
| Core diameter |
76.2 mm (3 in.) or 50.8 mm (2 in.) |
| Printing/cutting width (*1) |
Max. 1,600 mm (62.9 in.) |
Max. 1,346 mm (52.9 in.) |
| Ink |
Type |
Eco-Solvent Ink (TR3) 500 ml cartridge (only white 220 ml) |
| Colors |
Eight colors (Cyan, Magenta, Yellow, Black, Light Black, Green, Orange, and Red)
Eight colors (Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Orange, and Red)
Seven colors (Cyan, Magenta, Yellow, Black, Orange, Red, and White (2 cartridges))
Four colors (Cyan, Magenta, Yellow, and Black) |
| Printing resolution (dots per inch) |
Max. 1,800 dpi |
| Cutting speed |
10 to 300 mm/s (0.39 to 11.8 in/s) |
| Blade force (*2) |
30 to 500 gf |
| Blade |
Type |
Roland CAMM-1 series blade |
| Offset |
0.000 to 1.500 mm (0.0 to 59 mil) |
| Software resolution (when cutting) |
0.025 mm/step (0.98 mil/step) |
| Media heating system (*3) |
Print heater set temperature: 30 to 45 °C (86 to 113 °F)
Dryer set temperature: 30 to 55 °C (86 to 131 °F) |
| Connectivity |
Ethernet (100BASE-TX/1000BASE-T, automatic switching) |
| Power-saving function |
Automatic sleep feature |
| Rated input |
100-120 / 220-240 Va.c. 50 / 60 Hz 8.6 / 4.4 A |
| Power consumption |
During operation |
Approx. 1,140 W |
| Sleep mode |
Approx. 40 W |
| Acoustic noise level |
During operation |
66 dB (A) or less |
| During standby |
56 dB (A) or less |
Dimensions
(Width x Depth x Height) |
2,886 mm × 748 mm × 1,415 mm (113.62 in. x 29.45 in. x 55.71 in.) |
2,632 mm × 748 mm × 1,415 mm (103.62 in. x 29.45 in. x 55.71 in.) |
| Weight |
189 kg (417 lb.) |
182 kg (402 lb.) |
| Environment |
During operation (*4) |
Temperature: 20 to 32°C (68 to 89.6 °F), humidity: 35 to 80% RH (no condensation) |
| Not operating |
Temperature: 5 to 40°C (41 to 104°F), Humidity: 20 to 80% RH (no condensation) |
| Included items |
Dedicated stand, power cord, media take-up unit, media holders, replacement blade for separating knife, cleaning liquid bottle for maintenance, drain bottle, User's Manual, software (VersaWorks, Roland DG Connect), etc. |
